DX3 Triple 4K Display Universal Docking Station - with 100W Power Delivery

SKU: DUPRDX3-WW
Sale price$299.99
Sold out
User Manual
Specification Sheet
Mac Driver
Windows driver
Drivers
SMALL DESK FOOTPRINT. BIG PERFORMANCE

The DX3's compact design occupies minimal desk space to deliver premium performance. It's the ideal dock for a distraction-free desk set up focused on productivity.

USB-C & USB-A LAPTOP COMPATIBLE

IT decision-makers and organisations have more options with the DX3. It supports USB-C and USB-A laptop deployment.

DUAL/TRIPLE DISPLAY ON M1/M2 MAC

M1/M2 Mac users can work on up to three screens when they plug into the DX3.

Specifications
  • SKU: DUPRDX3-WW
  • Barcode (EAN): 9350784023827
  • Displays: Single display, Dual display, Triple display
  • Displays: Triple display
  • Host Connection Technology: USB-C
  • Operating System: Mac (Apple), iPad OS (Apple), Windows (Microsoft), Chrome OS (Google)
  • Mac Processor Type: M1/M2/M3, M1/M2/M3 Ultra/Pro/Max, Intel
  • Display supported on Mac M1/M2/M3: Single display, Dual display, Triple display
  • Display supported on Mac M1/M2/M3 Ultra/Pro/Max: Single display, Dual display, Triple display
  • Display supported on Mac Intel: Single display, Dual display, Triple display
  • Display supported on Windows: Single display, Dual display, Triple display
  • Display supported on Chrome: Single display, Dual display, Triple display
  • Display supported Universal: Single display, Dual display, Triple display
  • Video Outputs: DisplayPort
  • Docking Station Type: Desktop
  • Warranty: 2 Years
  • Laptop Charging: 100W
  • Physical Characteristics: Product Dimensions: 190 x 90 x 6.5mm (W x D x H) | Colour: Space Grey and Black | Weight (product): 535g | Materials: ABS
  • Additional Features: Ethernet, 3.5mm Audio, Card Reader
  • Compliance: FCC, CE, RoHS
  • Resolution: Up to 3 x 4K UHD 60Hz* | USB-A hosts limited to 2x 4K UHD 60Hz outputs | *See resolution support tables below for maximum outputs
  • Input: 1 x USB-C Port
  • Output: 3 x DisplayPort (DP1.4/DP++), 1 x USB-C 3.1 Gen 2 (10G) BC 1.2 and Apple Charging Support, 1 x USB-A 3.1 Gen 1 (5G) BC 1.2 and Apple Charging Support, 2 x USB-A 3.1 Gen1 (5G), 1 x 3.5mm TRRS Audio / Microphone Jack, 1 x RJ45 Ethernet 1Gbps, 1 x SD Card Re
  • Audio: Analogue audio line/microphone in/out
  • Device Compatibility: Apple, Chromebook, Microsoft
Downloads
User Manual
Specification Sheet
Mac Driver
Windows driver
Drivers

Customer Reviews

Based on 57 reviews
58%
(33)
35%
(20)
7%
(4)
0%
(0)
0%
(0)
100.0
D
David Tiggemann

Works great

S
Satinder Rana
An awesome product

I have used this product for over an year now. I have a macbook air and I was not sure if my mac will be able to support multiple external monitors. I bought this product as a leap of faith and thankfully this proved to be the right choice. There is no con in the products. It help me us 2 external monitors + macbook air screen. I use the fast charging Type C port to charge my iPhone. And there are more ports which I use for my mouse and keyboard. There is also micro SD card reader which help me to transfer my drone files without any hassles. Really happy with the product :)

R
Rodney Steele

DX3 Triple 4K Display Universal Docking Station - with 100W Power Delivery

D
Debbie Zabroske
DX3 Triple 4K Docking Station

I purchased this to use with my 2020 MacBook Air M1. I needed to utilize multiple monitors when working remote. This worked perfectly! Not only do I have my two monitors to use now, but the laptop screen acts as a 3rd Monitor. Setup was very easy. This was well worth the money and highly recommend.

S
Steve Dickinson
DX3 Triple 4K Display Universal Docking Station

First Alogic product. Easy to install and set up. Solved my problem of multiple displays for my MacBook Air, does everything I wanted of it so far. Highly recommended.
