Pink Shielded CAT6A LSZH Network Cable

SKU: C6A-0.5-Pink-SH
Length: 0.5m
Price:
$8.95
Stock:

Out of stock

Mother's Day Sale ✴️ | Get 20% Off Using Code MOM20

Icons_Canada_500x100_EX_Support
ALOGIC CAT6a shielded snagless patch cables are designed to meet and exceed the requirements for the next generation 10GBASE-T applications. The ALOGIC CAT6a cabling system provides an End to End solution that provides a guaranteed 750 Mhz of usable bandwidth. The ALOGIC CAT6a solution consists of Pre-terminated Cables, Patch Panels, Modular Jacks, Connectors and Bulk Installation Cables.
UP2QC10AWA-SGR

Features

Connect Your Ethernet Devices Performance rated for 750 MHz bandwidth. Suitable for up to 10G LANs, include 10GBASE-T Ethernet, 1000BASE-TX Fast Ethernet, & Lower. Each twisted pair in the cable is individually wrapped in aluminum foil Mylar (100% Coverage). Overall Copper Braided Shielded. Comes with LSZH (Low Smoke Zero Halogen) Jacket. Category 6A SFTP cable wired straight through. 26 AWG, gold plated 8x8 (RJ45) plugs. Suppresses ANEXT (Alien Near End Cross Talk) and delivers superior 10GbE performance up to 100mt. Warranty: Lifetime

Specifications
  • SKU: C6A-XX-Pink-SH
  • Barcode (EAN):
  • Standard: Category 6a TIA/EIA-568C-2.1
  • Temperature Rating: 75°C
  • Voltage Rating: 30V
  • Input: 8P8C (RJ45)
  • Connector: 50 micron gold-plated RJ45
  • Conductor Type: 26AWG (7/0.16), Stranded Bare Copper
  • Jacket: LSZH (Low Smoke Zero Halogen)
  • Compliance: A-Tick, ETL, UL, IEEE, RoHS Compliant
  • Warranty: 2 Years
